Security Single Swing Gate
The Security Single Swing Gate is a high-performance access control solution designed for commercial, industrial, and secure facilities requiring reliable, automated gate operation. Constructed from mild steel hollow sections, the gate frame is mitred and fully welded for structural integrity. SHS vertical bars, spaced at 140mm centres, are mounted inside the frame to provide enhanced security while maintaining a clean and uniform appearance.
This gate is suitable for automated or manual operation and is equipped with a powerful drive system capable of handling high-duty cycles and rapid operation in demanding environments.
Key Features:
-
Single leaf swing gate with a flat-top design
-
Frame constructed from mild steel hollow sections, mitred and welded
-
SHS vertical bars mounted at 140mm centres
-
Designed for high-security applications
-
Compatible with a wide range of access control systems
Drive System:
-
3-phase brake motor (0.55kW to 1.0kW)
-
100% duty cycle with adjustable opening/closing speeds
-
Limit and/or proximity switches for precise position sensing
-
Manual override for operation during power failure
-
Controlled via dedicated control board or optional PLC
-
Integrates with alarms, safety devices, strobe lights, and other peripherals
-
High-speed operation – up to 1 metre per second
Ideal Applications:
-
High-security commercial properties
-
Industrial facilities and logistics centres
-
Government and defence sites
-
Critical infrastructure and utility compounds
